PNQW3881ZA    TT1113WK0

Printed in Malaysia

Connections

Base unit

1 Connect the AC adaptor to the unit by pressing the plug firmly.

2 Fasten the cord by hooking it.

3 Connect the AC adaptor to the power outlet.

4 Connect the telephone line cord to the unit, then to the single-line telephone jack (RJ11C) until you hear a click.

5 A DSL/ADSL filter (not supplied) is required if you have a DSL/ADSL service.

Note:
L

Use only the supplied Panasonic AC adaptor PNLV226.

1

4

5

3

4

2

Charger

1 Connect the AC adaptor to the power outlet.

1

Model No.

 KX-TGE260/KX-TGE262/KX-TGE263

KX-TGE264/KX-TG454SK/KX-TGE270

KX-TGE272/KX-TGE273/KX-TGE274

KX-TGE275/KX-TG465SK

Quick Guide

TGE26x_27x_QG(en).fm  Page 1  Wednesday, December 11, 2013  9:03 PM
